iMessage API for Node.js and TypeScript

Building on the iMessage API? Build on iMessage with Flow: one agent for iMessage, WhatsApp and Telegram. New to it? Read the iMessage API guide.

Install and get a key

npm install @flow-engineer/messaging
npx @flow-engineer/messaging init

init creates a test key with no account, writes FLOW_MESSAGING_KEY to .env, adds .env to .gitignore, and prints a sandbox link. Open the link on your phone and tap Start. The sandbox runs on Telegram. The handler is the same on iMessage, so build here first. The iMessage API guide explains why Apple has no official API.

A test key allows one contact and 50 messages and expires after seven days. Sign in with a Flow account to keep the app.

The first reply

Save this as agent.ts and run node --env-file=.env agent.ts. It is the example from Flow’s quickstart:

import { FlowMessaging, contentText } from "@flow-engineer/messaging";

const flow = new FlowMessaging();
for await (const event of flow.events.stream({ types: ["message.received"] })) {
  const said = contentText(event.data.message.content);
  await event.conversation.reply("You said: " + said, {
    idempotencyKey: event.id,
  });
}

The stream reconnects and resumes for you, and needs no public URL, so it is the easiest way to develop on a laptop. Replace the echo with your model call. reply() also accepts a model stream and sends complete chat bubbles as they are ready. See iMessage agent with the Vercel AI SDK for a worked example.

Receive events in production

In production, register an HTTPS endpoint with POST /v1/webhook_endpoints and verify every delivery. This is the Express example from Flow’s docs:

import express from "express";
import { FlowMessaging, contentText } from "@flow-engineer/messaging";

const flow = new FlowMessaging();
const app = express();

// The raw body is required: a parsed and re-serialized body will not match.
app.post("/flow", express.raw({ type: "application/json" }), async (req, res) => {
  let event;
  try {
    event = await flow.webhooks.constructEvent(req.body, req.header("Flow-Signature"), process.env.FLOW_MESSAGING_WEBHOOK_SECRET!);
  } catch {
    return res.status(400).end();
  }
  if (event.type === "message.received") {
    return res.json(flow.webhooks.reply(`You said: ${contentText(event.data.message.content)}`));
  }
  res.json({});
});

app.listen(3000);

Answering in the webhook response is the fastest path, and Flow waits 10 seconds for it. For slower work, return {} at once and send the reply later. iMessage webhooks: signing, retries and ordering explains what happens when your endpoint is down.

To try the handler on localhost with no tunnel, run npx @flow-engineer/messaging listen --forward-to http://localhost:3000/flow. It forwards each event from the live stream, signed like a real delivery.

No SDK: use fetch

The API is plain HTTP, so fetch works. This is the reply call from the docs:

await fetch(`https://api.flow.engineer/v1/conversations/${conversationId}/messages`, {
  method: "POST",
  headers: {
    Authorization: `Bearer ${process.env.FLOW_MESSAGING_KEY}`,
    "Content-Type": "application/json",
    "Idempotency-Key": event.id,
  },
  body: JSON.stringify({ content: { type: "text", text: "Hello from my agent" } }),
});

Send iMessage programmatically lists the errors to handle, such as rate_limited and outside_window.

Other languages: Python and Go.
